Magnetic Buttons

Basic Info

Model NO.	HY-023
Appearance	Various as You Wish
Mold	Magnet Neodymium
Max Operation Temp	220 Degree Centigrade
Product Approved	RoHS
Company Management	ISO/Ts 16949:2009
Coatings	Ni, Zn, Gold, Copper, Epoxy, etc
Standard Specification	N35-54, N35m-52m, 33h-50h, 33sh-45sh...
Shape & Size	Customed Design
Transport Package	Carton
Specification	ROHS
Trademark	COCO
Origin	China Mainland
HS Code	85051110
Production Capacity	2000 Tons Per Year

Product Description

Manufacturer Neodymium Magnets

Our Machines:
(01) Vacuum Melting Furnaces 2 sets (300KGS)
(02) HDDR Furnaces 2 sets (1 TONS)
(03) Jet Milling Furnaces 3 sets (2X80KGS, 1X300KGS)
(04) Vacuum Sintering Furnaces 10 sets (10X500KGS)
(05) Grinder 20 sets
(06) WEDM 300 sets
Test Equipment
(01) Magnetic Measurement for Permanent Magnets 1 set
(02) Highly Accelerated Stress Tester- HAST 2 sets
(03) Image Measuring Instrument 2 sets
(04) X-ray Coating Thickness Gauge 2 sets
(05) Electro-Thermostatic Blast Oven 3 sets
(06) Salty Spray Test Chamber 3 sets
Experienced Engineers: 5 persons
QC: 8 persons

Product Description:

1. Materials: Ne-Fe-B

2. Shape: Various as you wish

3. Certificate: ISO/TSI6949: 2009

4. Powerful: Neodymium magnets (sintered NdFeB magnets) are more powerful than any other permanent magnet material in the market today.

5. Wide product range: N35-N54, 35M-52M, 33H-50H, 33SH-45SH, 30UH-42UH, 30EH-38EH, and 28AH-33AHB.

6. High performance: High intrinsic coercive force (up to 35KOe) and energy product (up to 55MGOe), the maximum working temperature of 230 degrees Celsius.

7. Competitive price: Very competitive price (lower than market average) due to mass production.

8. Coating: All the neodymium magnets oxidize rapidly when exposed, so an anti-corrosive coating (usually electroplating) is used to extend their working life. Such as Ni, Zn, gold, copper, epoxy, chemical, parylene and so on;

9. Applications: Magnet Separators, Sensors, Motors, Rotors, Wind turbines, Wind generators, Loudspeakers, Magnetic hooks, Magnetic holder, Filters Automobiles Magnetic jewelries, toys, magnetic buttons, Magnetic therapy and so on;

10. Quality: As to give good service, quality of each piece is guaranteed. Every piece of magnets is tested by ISO/TS 16949: 2009.

11. Caution: You should be extremely careful when install neodymium magnet, as they can easily pinch fingers.

12. No for Kids: NdFeB magnets are not suitable for children.



Production process:

Raw Materials-->Mixture--->Vacuum Melting--- > Powder Production--- >Molding ---> Vacuum Sintering--- > Testing--- >Mechanical Processing--- > Surface Coating--- >Magnetized--- > Inspecting--- > Packing and ShippingDirections of Magnetization:

Directions of magnetization
A. Thickness Magnetized
B. Axially Magnetized
C. Diametrally Magnetized
D. Multi-poles magnetized
E. Radial Magnetized
F. Customized specific requirements magnetized



Inquiry

To receive a quote for Neodymium magnets, please provide the following details:

(01) Outer Diameter, Inner Diameter or, Degree of Angle;
(02) Thickness, Length;
(03) Grades;
(04) Coating;
(05) Tolerances and Magnetization Direction (North on the Outside Face / South on the Outside Face / Magnetized through Circumference / Magnetized through Thickness ).
(06) Testing Conditions

Contact Person: Cathy
MB: 008618958304686

Item	Grade	Remanence;Br				Coercive Force;bHc		Intrisic Coercive Force;iHc		Max Energy Product;(BH)max				Working Temp.
		kGs		T		kOe	KA/m	kOe	KA/m	MGOe		KJ/m3
		Max.	Min.	Max.	Min.					Max.	Min.	Max.	Min.
N	N54	15.1	14.5	1.51	1.45	≥10.5	≥836	≥11	≥876	55	51	438	406	≤80
	N52	14.8	14.2	1.48	1.42	≥10.5	≥836	≥11	≥876	53	49	422	390	≤80
	N50	14.5	14.0	1.45	1.40	≥11.0	≥876	≥12	≥955	51	47	406	374	≤80
	N48	14.3	13.7	1.43	1.37	≥11.0	≥876	≥12	≥955	49	45	390	358	≤80
	N45	13.8	13.2	1.38	1.32	≥11.0	≥876	≥12	≥955	46	42	366	334	≤80
	N42	13.5	12.9	1.35	1.29	≥11.0	≥876	≥12	≥955	44	40	350	318	≤80
	N40	13.2	12.6	1.32	1.26	≥11.0	≥876	≥12	≥955	41	38	334	302	≤80
	N38	13.0	12.2	1.30	1.22	≥11.0	≥876	≥12	≥955	40	36	318	287	≤80
	N35	12.2	11.7	1.22	1.17	≥10.9	≥868	≥12	≥955	36	33	287	263	≤80
M	N52M	14.8	14.2	1.48	1.42	≥13.3	≥1059	≥14	≥1114	43	49	422	390	≤100
	N50M	14.5	14.0	1.45	1.40	≥13.1	≥1043	≥14	≥1114	41	47	406	374	≤100
	N48M	14.3	13.7	1.43	1.37	≥12.8	≥1019	≥14	≥1114	49	45	390	358	≤100
	N45M	13.8	13.2	1.38	1.32	≥12.4	≥987	≥14	≥1114	46	42	366	334	≤100
	N42M	13.5	12.9	1.35	1.29	≥12.1	≥963	≥14	≥1114	44	40	350	318	≤100
	N40M	13.2	12.6	1.32	1.26	≥11.8	≥939	≥14	≥1114	41	38	334	302	≤100
	N38M	13.0	12.2	1.30	1.22	≥11.7	≥915	≥14	≥1114	40	36	318	287	≤100
	N35M	12.2	11.7	1.22	1.17	≥10.9	≥868	≥14	≥1114	36	33	287	263	≤100
H	N50H	14.5	14.0	1.45	1.40	≥12.9	≥1027	≥16	≥1274	51	47	406	374	≤120
	N48H	14.3	13.7	1.43	1.37	≥12.7	≥1011	≥16	≥1274	49	45	390	358	≤120
	N46H	14.0	13.4	1.40	1.34	≥12.5	≥995	≥17	≥1353	47	43	374	342	≤120
	N44H	13.7	13.1	1.37	1.31	≥12.3	≥979	≥17	≥1353	45	41	358	326	≤120
	N42H	13.5	12.9	1.35	1.29	≥12.1	≥963	≥17	≥1353	44	40	350	318	≤120
	N40H	13.2	12.6	1.32	1.26	≥11.8	≥939	≥17	≥1353	42	38	334	302	≤120
	N38H	13.0	12.2	1.30	1.22	≥11.5	≥915	≥17	≥1353	40	36	318	287	≤120
	N35H	12.4	11.7	1.24	1.17	≥11.0	≥876	≥17	≥1353	37	33	295	263	≤120
	N33H	11.7	11.3	1.17	1.13	≥10.5	≥836	≥17	≥1353	34	31	271	247	≤120
SH	N45SH	14.0	13.4	1.40	1.34	≥12.5	≥995	≥20	≥1592	47	43	374	342	≤150
	N44SH	13.7	13.1	1.37	1.31	≥12.3	≥979	≥20	≥1592	45	41	358	326	≤150
	N42SH	13.5	12.9	1.35	1.29	≥12.1	≥963	≥20	≥1592	44	40	350	318	≤150
	N40SH	13.2	12.6	1.32	1.26	≥11.8	≥939	≥20	≥1592	42	38	334	302	≤150
	N38SH	12.9	12.2	1.29	1.22	≥11.5	≥915	≥20	≥1592	40	36	318	287	≤150
	N35SH	12.4	11.7	1.24	1.17	≥11.0	≥876	≥20	≥1592	37	33	295	263	≤150
	N33SH	12.1	11.4	1.21	1.14	≥10.7	≥852	≥20	≥1592	35	31	279	247	≤150
UH	N42UH	13.5	12.9	1.35	1.29	≥12.1	≥963	≥25	≥1990	44	40	350	318	≤180
	N40UH	13.2	12.6	1.32	1.26	≥11.8	≥939	≥25	≥1990	42	38	334	302	≤180
	N38UH	12.9	12.2	1.29	1.22	≥11.5	≥915	≥25	≥1990	40	36	318	287	≤180
	N35UH	12.4	11.7	1.24	1.17	≥11.0	≥876	≥25	≥1990	37	33	295	263	≤180
	N33UH	12.1	11.4	1.21	1.14	≥10.7	≥852	≥25	≥1990	35	31	279	247	≤180
	N30UH	11.6	10.8	1.16	1.08	≥10.2	≥812	≥25	≥1990	32	28	255	223	≤180
EH	N38EH	12.9	12.2	1.29	1.22	≥11.5	≥915	≥30	≥2388	40	36	318	287	≤200
	N35EH	12.4	11.7	1.24	1.17	≥11.0	≥876	≥30	≥2388	37	33	295	263	≤200
	N33EH	12.1	11.4	1.21	1.14	≥10.7	≥851	≥30	≥2388	35	31	279	247	≤200
	N30EH	11.5	10.8	1.15	1.08	≥10.2	≥812	≥30	≥2388	32	28	255	223	≤200
AH	N33AH	12.1	11.4	1.21	1.14	≥10.7	≥852	≥35	≥2786	35	31	279	247	≤230
	N30AH	11.5	10.8	1.15	1.08	≥10.2	≥812	≥35	≥2786	32	28	255	223	≤230
	N28AH	11.2	10.4	1.12	1.04	≥9.70	≥772	≥35	≥2786	30	26	239	207	≤230
